MRCOOL® DIY® Series 5th gen Outtasight® 9K BTU 230V One-Way Ceiling Cassette
$1,410.00
Have Questions?
Chat, Call, or Text a Specialist
Found a better price? We will match or beat it! 1-844-945-3625
- Description
- Best Price Guarantee!
- Why Buy From Us
Description
Low-Profile 9,000 BTU Ceiling Comfort with True DIY Installation
The MRCOOL® DIY® Series 5th Gen OuttaSight® 9K One-Way Ceiling Cassette delivers efficient heating and cooling for spaces up to 400 sq. ft. while staying completely out of sight. Designed to fit between 16-inch ceiling joists, this cassette preserves wall space and installs easily using pre-charged Quick Connect® line sets, eliminating the need for vacuuming, special tools, or HVAC certification.
Factory-charged with R-454B refrigerant, this unit meets current EPA standards and pairs seamlessly with MRCOOL® DIY® 5th Gen multi-zone condensers. Quiet operation, smart control options, and easy filter access make it a practical choice for bedrooms, offices, and living areas where clean design and reliable comfort matter.
Important Notes
- Designed for use with MRCOOL® DIY® multi-zone condensers only
- Pre-charged with R-454B refrigerant
Low-profile and easy to hide
Low-profile installation that disappears into your space while delivering dependable heating and cooling.
Key Features and Benefits
- 9,000 BTU Heating & Cooling Capacity - Effectively conditions rooms up to 400 sq. ft. without oversizing or wasted energy.
- One-Way Ceiling Cassette Design - Directs airflow evenly while staying hidden above the ceiling for a clean, modern look.
- DIY Quick Connect® Compatibility - Pre-charged line sets eliminate vacuuming, refrigerant handling, and special tools.
- R-454B Refrigerant - Low-GWP refrigerant meets updated EPA requirements and supports efficient operation.
- Whisper-Quiet Performance - Operates as low as 24 dBA, making it ideal for noise-sensitive spaces.
- Smart & Voice Control Ready - Works with the SmartHVAC app, Amazon Alexa, and Google Assistant for hands-free comfort.
- Elevation Panel for Easy Maintenance - Drop-down grille allows fast filter access without removing ceiling panels.
- Reusable Air Filter - Improves indoor air quality while reducing replacement costs.
- Designed for Multi-Zone Systems - Pairs seamlessly with MRCOOL® DIY® 5th Gen multi-zone outdoor condensers.
- Strong Warranty Coverage - Includes a 5-year parts warranty, 7-year compressor warranty, and limited lifetime compressor warranty with registration.
System Specifications
- Cooling Capacity (BTU): 9,000
- Heating Capacity (BTU): 9,000
- Voltage Requirements: 208–230
- Phase: 1
- Cycle: 60
- Max Fuse Breaker (A): 15
- Min Circuit Ampacity (A): 3
- Rated Load: 0.8
- Decibel Rating (dBA): 36
- Decibel Rating (Low) (dBA): 24
- Decibel Rating (High) (dBA): 38
- CFM: 341 / 294 / 259 / 235 / 235
- Blower Motor RPM: 1104 / 994 / 784
- Filter Type: Reusable
- Fan Only Option: Yes
- Quiet Mode: Yes
- Sleep Mode: Yes
- Auto Cool: Yes
- WiFi Compatibility: Yes
- App Compatibility: Yes
- Works With iOS: Yes
- Works With Android: Yes
- Remote Control Included: Yes
- Registered Warranty: Limited Lifetime Compressor
- Base Warranty: 5-Year Parts / 7-Year Compressor
- Base Parts Warranty: 5-Year Parts
- Registered Compressor Warranty: Limited Lifetime Compressor
- Base Compressor Warranty: 7-Year Compressor
- Has Batteries: Yes
- Contains Electronics: Yes
- Contains Chemicals: Yes
- Contains Aerosol: Yes
- Contains Compressed Gas: Yes
- Proposition 65 Warning: Yes
- Restricted States: GU; PR; VI
- Net Depth (in): 13.19
- Net Height (in): 8.98
- Net Width (in): 50.31
- Net Weight (lbs): 45
- Gross Depth (in): 22.48
- Gross Height (in): 22.64
- Gross Width (in): 57.60
- Gross Weight (lbs): 88
Frequently Asked Questions
What size space can the MRCOOL DIY OuttaSight 9K ceiling cassette handle?
It’s rated for areas up to 400 sq. ft., making it ideal for bedrooms, offices, studios, and small living spaces.
Can this ceiling cassette be installed without professional HVAC tools?
Yes. It connects using MRCOOL DIY® Quick Connect® line sets that are pre-charged with R-454B, eliminating the need for vacuuming or specialized tools.
Is this unit compatible with MRCOOL DIY multi-zone condensers?
Yes. It’s designed specifically for MRCOOL DIY® 5th Gen multi-zone outdoor units.
How quiet is the MRCOOL OuttaSight 9K during operation?
Sound levels operate as low as 24 dBA, making it well-suited for quiet, noise-sensitive rooms.
